Product Overview
This seed drill is a high-end piece of agricultural equipment developed by our company, Qingdao Dashun Jingfeng, for precision vegetable sowing.
The machine's core technology utilises the principle of negative pressure adsorption: a fan provides a stable negative pressure, precisely adhering the seeds to the suction holes on the sowing disc; when the sowing disc rotates to the sowing position, the seeds are smoothly released due to a change in pressure.
Depending on the size of the seeds (such as small seeds like spinach and coriander, medium-sized seeds like cabbage and celery, and large seeds like carrots and radishes), the pressure can be adjusted as required and the suction cups replaced to ensure accurate and even sowing.
Specifications
| Tractor-carried 3 Ridge 6 Row Air Suction Planter | |||
| Type | 2BS-6H | Function | Rotary Tillage, Ridging, Drip Irrigation, Air-suction Seeding, Real-time Monitoring |
| Matching Power(Kw/hp) | 95-180 | Matching form | Three Point Suspension |
| Ridge width(mm) | 700/800/900 | Dimensions(mm) | 2450*2300/2600/2900*1350 |
| Number of work lines ( lines ) | 6 | Row Spacing(mm) | 180-400 |
| Plant Spacing(mm) | 20-600 | Sowing Depth(mm) | 0-20 |
| Drip irrigation tape (strip) | 3 | Drip irrigation depth(mm) | 0-20 |
| Scope of Application | Onion,Carrot ,Beet,Celery,Lettuce,Cabbage,Coriander,Spinach etc. | ||
Key Features
Our air-suction seed drill utilises vacuum seeding technology; by adjusting the seed dispenser, it can achieve either a single seed per hole or multiple seeds per hole, thereby minimising instances of double sowing or missed seeds.
Furthermore, we offer customisation options to tailor the number of rows to the customer's requirements and precisely adjust plant spacing.
This is also a multi-functional pneumatic seeder; a single machine can perform rotary tilling, ridge formation, drip tape laying, pneumatic seeding, real-time monitoring and soil compaction.
It can also be fitted with a fertiliser hopper and mulching device, enabling simultaneous fertilisation and seeding, followed by immediate mulching after sowing, thereby maximising operational efficiency.
Product Details
1.Pressure gauge
The pressure level can be monitored via the pressure gauge to prevent it from becoming too high or too low; excessive pressure accelerates wear between the suction cup and the seal, whilst insufficient pressure prevents the seeds from being sucked up.
2.Parallelogram structure
Can be adjusted to follow the undulations of the ridges, ensuring a uniform sowing depth, uniform and vigorous seedling emergence, and high-quality produce with excellent yields.
3.Seed recovery device
Recovers seeds from seed trays without affecting seed purity, facilitating reuse
Benefits for Customers
Using our pneumatic vegetable seed drill is not merely an upgrade to your equipment-it also helps you improve sowing efficiency, reduce cultivation costs and maximise your farm's profitability.
Our seed drill helps to reduce seed costs
Pneumatic sowing ensures precise placement of every seed, minimising missed sowings, double sowings and seed wastage. This allows for more efficient use of every seed, thereby reducing overall cultivation costs.
Our seed drill helps to reduce labour costs
Automated, precision sowing significantly reduces the need for manual sowing and thinning, enabling more work to be completed in less time with fewer workers.
Our seed drill improves sowing accuracy
Customisable row spacing, adjustable plant spacing and sowing depth ensure that every seed is precisely positioned, creating ideal growing conditions across the entire field.
Payment method
To safeguard the interests of both the buyer and the seller, we offer a flexible range of payment methods, which can be agreed upon in accordance with the customer's requirements. The specific payment methods are as follows:
Domestic customers:
Full payment
After the customer confirms the order, they pay the full amount at once. The company will arrange production and delivery. Full payment allows for certain price discounts.
Installment payment
After the customer confirms the order, they pay 30% as a deposit. The company arranges production, and after production is completed, the customer pays the remaining amount. The company then arranges delivery and installation/testing.
International customers:
T/T payment
The customer pays 30% as a deposit. The company arranges production and shipment. After receiving the bill of lading, the customer pays the remaining amount. This method suits most international customers.
Different configurations can be selected to suit varying requirements
To cater for different crops, sowing methods and diverse requirements, our pneumatic vegetable seeders allow you to choose from a range of configurations to meet your specific needs.
1.Selectable number of rows
Our seeders offer a range of options, such as 2, 4, 6, 8, 12, 16 or 20 rows, or a bespoke number of rows tailored to the customer's sowing area and tractor size.
2.Customisable row spacing
The row spacing on our seeders can be customised to suit the specific requirements of different crops, ensuring optimal growing space and efficient field management.
3.Adjustable Plant Spacing
Plant spacing can be easily adjusted by replacing the suction cups or adjusting the spacing control unit, enabling precise control of spacing for different crops and planting densities.
4.Interchangeable Seeding Discs
Our seed drill comes equipped with a set of seed discs for the main crops as standard; discs for additional crops are available at extra cost. This allows for easy switching between seed discs for onions, carrots, spinach, lettuce, cabbage, radishes, beetroot, celery, coriander and many other vegetables.
5.Optional fertiliser application system
The optional fertiliser application unit for our seed drill enables simultaneous sowing and fertiliser application, improving nutrient utilisation whilst reducing field operation time and labour costs.
FAQ
1. Why choose an air-suction seed drill for sowing?
Because it enables precise sowing of vegetables, improves sowing consistency, and significantly increases sowing efficiency.
2. Does an air-suction seed drill save seeds?
Yes. The precise sowing system minimises seed damage and effectively prevents missed or double sowing.
3. Can an air-suction seed drill improve vegetable quality?
Yes. Uniform plant spacing creates better growing conditions for crops, resulting in higher yields and better quality vegetables.
4. Is the pneumatic seed drill suitable for large-scale vegetable cultivation?
Yes. Pneumatic seed drills are specifically designed for efficient sowing operations in medium to large-scale vegetable growing areas.
5. Can the pneumatic seed drill adapt to different soil conditions?
Yes. Pneumatic seed drills perform excellently on prepared farmland and can adapt to a variety of soil types.
