Product Overview
The 2DX-2H is a two-row pneumatic vegetable seeder designed to mount on tractors for use in commercial vegetable production and cooperative farming operations. Its compact footprint and straightforward design make it suitable for growers who need a reliable planting implement that can handle ridged beds as well as flat ground, while maintaining accurate row alignment even when field surfaces are less than perfectly level. The floating parallelogram linkage on each planting unit helps the seeder follow ground contours, reducing the risk of depth variations that can lead to uneven emergence.
Key Features
Single-Pass Field Operation – By combining soil preparation, bed shaping, drip tape placement, seed metering, furrow closing, and light compaction into one pass, the machine cuts down on multiple trips across the field. Growers benefit from lower fuel consumption, reduced labor hours, and less soil disturbance compared to running separate implements for each step.
Broad-Range Plant Spacing Adjustment – With spacing adjustable from approximately 20 mm up to 600 mm, the seeder adapts to a wide variety of crop types, plant populations, and market specifications. This range allows operators to fine-tune seeding rates without needing to swap major components or keep multiple dedicated machines for different crops.
Seed Plate Versatility – Seed plates are chosen based on the physical characteristics of the specific seed being planted-size, shape, and any coating or pelleting applied. This modular approach enables the same base machine to shift between crop types simply by installing the appropriate plate, improving utilization across the growing season.
Precision Vacuum Singulation – The negative-pressure metering system draws seeds individually onto the plate and releases them into the furrow at controlled intervals. This method improves singulation accuracy, reducing the frequency of multiple-seed drops or gaps that can affect crop uniformity and final yield.
Technical Specifications
| Parameter | Detail |
|---|---|
| Product Model | 2DX-2H |
| Product Type | 2-Row Pneumatic Vegetable Seeder |
| Number of Rows | 2 |
| Working Width | Approx. 600 mm |
| Overall Dimensions | 1650 × 1450 × 1300 mm |
| Recommended Tractor Power | ≥ 50 HP |
| Plant Spacing Range | Approx. 20–600 mm |
| Standard Row Spacing | Approx. 600 mm |
| Sowing Depth Range | Approx. 0–30 mm |
| Seeding Method | Pneumatic vacuum / negative pressure |
| Drive System | PTO-driven from tractor |
| Field Capacity | Up to approx. 5 acres/hour* |
| Hitch Type | Three-point linkage |
| Seed Metering | Crop-specific vacuum plates |
| Suitable Seed Types | Raw, coated, or pelleted (subject to configuration) |
Intended Crop Range
The 2DX-2H is built primarily for open-field vegetable production and handles a variety of crop types including onion, beet, white radish (daikon), and Chinese cabbage. Other vegetable varieties may also be suitable, though seed characteristics should be evaluated in advance to confirm the correct metering plate and machine settings.
Configuration & Customization Options
The machine can be adjusted to match specific crop, seed, tractor, and field conditions. Available modifications include plant spacing adjustments, row spacing variations, drip tape installation equipment, ridge-forming attachments, and optional seed monitoring systems. For distributors and larger buyers, cosmetic and branding options such as machine color, customer logo placement, and private-label documentation are also available. OEM/ODM configurations can be developed according to agreed specifications.
Pre-Delivery Quality Checks
Each machine goes through a series of inspection points before shipment to confirm that it meets assembly and operational standards. These checks cover mechanical assembly integrity, vacuum and metering system function, smooth rotation of seed plates, planting-unit articulation and movement, transmission component operation, and where fitted, electrical and monitoring system performance. A complete machine run test is conducted as part of the verification process. Buyers may request production and testing photos or videos to be provided as part of the order documentation, offering visibility into the quality assurance steps completed before the machine is crated for dispatch.
FAQ
Q: Can you supply spare seed plates for different crops?
A: Yes. Additional crop-specific seed plates are available, allowing the same machine to be configured for different suitable seed types as cropping programs change.
Q: Can you manufacture the machine according to our tractor specifications?
A: Yes. Provide the tractor model, PTO information, and hitch specifications, and we will check the machine configuration for compatibility before order confirmation.
Q: What is the MOQ for distributors?
A: Standard orders can be discussed from one unit upward. Distributor quantities are quoted separately with volume pricing.
Q: Can you provide OEM or private-label machines?
A: Yes. OEM options include customer logos, machine colors, labels, and agreed configuration changes to meet specific market requirements.
Q: What is the production lead time after order confirmation?
A: Lead time depends on the configuration and order quantity. The confirmed production schedule will be stated in the quotation or sales contract.
